IHC3808-001G-1000BZ1-5L hollow shaft rotary encoder
Miniature size, easy assembling
2 quadrature output channel (A&B) + index signal
Resolution up to 1000 ppr
Housing size: 38mm, shaft dia: 8mm
online service
IHC3808-001G-1000BZ1-5L hollow shaft rotary encoder
Features
● Miniature size, easy assembling
● 2 quadrature output channel (A&B) + index
signal
● Resolution up to 1000 ppr
● Housing size: 38mm, shaft dia: 8mm
· Model: IHC3808-001G-1000BZ1-5L
· Brand: YUMO
· Code: YM0000004
Feature
●ASIC devices internal, good reliability, long life, anti-jamming performance.
●Stainless steel shaft has a higher stability and protection.
●Metal shell is more solid and anti-impact.
●Outlet end use waterproof metal interface protection
●Bearing load heavy, anti-oil and water.
●Applicability to a wide variety of mechanical and industrial control.
●Resolution up to 5400 pulse.
●10 ~ 5400 pulses Optional: (Other pulses available on request)
