G14-3A10NC Diffused Reflection Type NO+NC Output Photoelectric Switch
The mechanical quantity to be measured, such as displacement, pressure change into an electrical capacitance sensor. Therefore, capacitive sensors can be divided into pole pitch change type, area change type, change the media type categories. Pole pitch change type is generally used to measure the tiny lines or due to force displacement, pressure, vibration caused by the pole pitch changes (see capacitive pressure sensor). Area change type is generally used to measure the angular displacement or larger linear displacement. Change media type commonly used in level measurement and a variety of medium temperature, density determination and humidity.
Model:G14-3A10NC
Brand: YUMO
online service
Diffuse Type
Diffuse reflection type photoelectric switch integrates the transmitter and the reciver. Light reflected by the photoelectric switch is reflected back to the receiver by the detected object.
Electrical Datasheet
| Outward appearance illustration | G14 | |||
| Overall dimensions |
 |
|||
| Diffuse type | Detection distance | 10cm | ||
| 10-30VDC | NPN | NO | G14-3A10NA | |
| NC | G14-3A10NB | |||
| NO+NC | G14-3A10NC | |||
| PNP | NO | G14-3A07PA | ||
| 90-250VAC | NC | G14-3A07PB | ||
| NO+NC | G14-3A07PC | |||
| Retroreflective type | Detection distance | 1m | ||
| 10-30VDC | NPN | NO | G14-3B1NA | |
| NC | G14-3B1NB | |||
| NO+NC | G14-3B1NC | |||
| PNP | NO | G14-3B1PA | ||
| 90-250VAC | NC | G14-3B1PB | ||
| NO+NC | G14-3B1PC | |||
| Through beam | Detection distance | 3m | ||
| 10-30VDC | NPN | NO | G14-3C3NA | |
| NC | G14-3C3NB | |||
| NO+NC | G14-3C3NC | |||
| PNP | NO | G14-3C3PA | ||
| 90-250VAC | NC | G14-3C3PB | ||
| NO+NC | G14-3C3PC | |||
| DC/SCR Control output | DC:200mA | |||
| DC/AC Consumption current | DC<15mA | |||
| DC/AC Response time | Dc<2ms | |||
| Directional angle | 3° -10° | |||
| Detected object | transparent or opaque body | |||
| Working environment temperature | -25ºC~+55ºC | |||
| Intensity of illumination of working environment | Sunlight under 1000LX incandescent lamp under 3000LX | |||
| Shell material | Plastic | |||
| Protection grade | IP54 | |||
