S-1500-12 High Quality 1500W 12VDC SMPS Switching Power Supply

YUMO Switching power supply products are widely used in industrial automation control, military industry equipment, scientific research equipment, LED lighting, industrial control equipment, communications equipment, electrical equipment, instrumentation, medical equipment, semiconductor refrigeration and heating, air purifier, electronic refrigerator, LCD, LED lamps and lanterns, communications equipment, audio and video products, security monitoring, LED lights belt, computer case, digital products and instruments, etc.

online service

Tel:0086-15356229951

Email: sale@yingselectric.com

Skype: benjaminying

PDF Download
Inquiry
The previous
Next

Information

Switching Power Supply 1000W Single phase output S-1500-12
switching power supply,switch power supply,DC power supply
Protection:Over load,over voltage,short circuit
Professional export

Industrail Switching Power Supply

(1) high efficiency and good price.

(2) CE RoHS certification.

(3) good quality and timely delivery.

Industrial switching power supply (s-1500)

Model S - 1500

Ac input voltage range 100-120vac / 200-240vac switch select 50-60hz: 12VDC.

Input current 10A / 20A.

AC surge current cold start current 60A / 230V.

Leakage current<3.5mA / 240VAC.

Overroad protection 105% - 135% type: current limit automatic recovery.

Overload protection 110-135%.

Set the upkeep time 1.5ms.50ms20ms.

Working temperature - 10 ℃ to + 50 ℃ 20% 90% RH

Pressure input/output interval: 1.5VAC input and shell 1.5KVAC output and 0.5KVAC.

Weight/package 3.0Kg.

EMC CISPR22 (EN5022) CLASSB. Iec 801-2.3.4. Iec 555-2.

Model S-1000-12 S-1000-15 S-1000-24 S-1000-27 S-1000-48
 DC output voltage  12V  15V  24V  27V  48V
 Output voltage error  ±10%  ±10%  ±5%  ±5%  ±5%
 Rated output current  80A  67A  40A  37A  20A
 Output current range  0-80A  0-67A  0-40A  0-37A  0-20A
 Wave and noise  200mVp-p  200mVp-p  240mVp-p  240mVp-p  300mVp-p
 Inlet stability  ±0.5%  ±0.5%  ±0.5%  ±0.5%  ±0.5%
 Load stability  ±0.5%  ±0.5%  ±0.5%  ±0.5%  ±0.5%
 DC output power  960W  1005W  960W  999W  960W
 Efficiency 75% 75% 78% 80.00% 84.00%
 Adjustable range for DC voltage   10~13.2V  13.5~18V  20~26.4V  24~30V  41~56V
