G33 Infrared ray Photoelectric Switch Sensor

The mechanical quantity to be measured, such as displacement, pressure change into an electrical capacitance sensor. Therefore, capacitive sensors can be divided into pole pitch change type, area change type, change the media type categories. Pole pitch change type is generally used to measure the tiny lines or due to force displacement, pressure, vibration caused by the pole pitch changes (see capacitive pressure sensor). Area change type is generally used to measure the angular displacement or larger linear displacement. Change media type commonly used in level measurement and a variety of medium temperature, density determination and humidity.

OVERALL DIMENSIONS

G33 Infrared ray Photoelectric Switch Sensor


D
i
f
f
u
s
e

T
y
p
e



 Detection distance

50cm


10-
10
VDC


NPN

NO

G33-3A10NA

NC

G33-3A10NB

NO+NC

G33-3A10NC


PNP

NO

G33-3A10PA


90~
250
VAC

NC

G33-3A10PB

NO+NC

G33-3A10PC

SCR

ControHable
silicon

NO


NC


Relay output




R
e
t
r
o
r
e
f
l
i
c
t
i
v
e



 Detection distance

1m


10-
10
VDC


NPN

NO

G33-3B1NA

NC

G33-3B1NB

NO+NC

G33-3B1NC


PNP

NO

G33-3B1PA


90~
250
VAC

NC

G33-3B1PB

NO+NC

G33-3B1PC

SCR

ControHable
silicon

NO


NC


Relay output





T
r
o
u
g
h

b
e
a
m



Detection distance

3m


10-
10
VDC



NPN

NO

G33-3C3NA

NC

G33-3C3NB

NO+NC

G33-3C3NC


PNP

NO

G33-3C3PA


90~
250
VAC

NC

G33-3C3PB

NO+NC

G33-3C3PC

SCR

ControHable
silicon

NO


NC


Relay output



        DC/SCR/Control output

DC:200mA、AC:100mA

        DC/AC Consumption current

DC<15mA、AC<10mA

       DC/AC Response time

Dc<2ms、AC<20mA

       Directional angle

3。-10。

       Detected object

transparent or opaque body

       Working envirnment temperature

25℃~+55℃

       Intensity of illumination of working environment

incandescentlamp under 1000LX

       Shell materia

Plastic

      Protection grade

IP54
