 Home » Products » Shaft Encoders » ISC2504-001E-200B-5C shaft diameter 4mm 5VDC Solid Shaft Incremental Rotary Encoder

ISC2504-001E-200B-5C shaft diameter 4mm 5VDC Solid Shaft Incremental Rotary Encoder

◆ Features
● Miniature size, easy assembling
● 2 quadrature output channel (A&B) + index signal
● Housing size 25mm, shaft dia. 4mm

online service

Tel:0086-15356229951

Email: sale@yingselectric.com

Skype: benjaminying

PDF Download
Inquiry
The previous
Next

ISC2504-001E-200B-5C shaft diameter 4mm 5VDC Solid Shaft Incremental Rotary Encoder

Product Description

Application

Measure the distance, automatic control , robot, X-Y labor ,printing,  curtained door, shoe machine , textile machine and etc.



Features

Miniature size, easy assembling

2 quadrature output channel (A&B) + index signal



Model NO. ISC2504-001E-200B-5C
Shaft diameter 4mm
Output form

Open collector NPN

Output signal A,B phases
Housing diameter 25mm
Pulses 200P/R
Supply voltage 5VDC
Cable lead out Cable lead out behind
Load current 40mA
Protection grade IP51



Ordering Information


 Technical Specification

 Electrical  Specification
Output circuit Open collector   Voltage output Push pull output Line driver output
Power Vcc 5~30 5~30 5±0.25   5~30 5±0.25 5~30
Current ≤80mA ≤80mA ≤80mA ≤150mA
Load current 40mA 40mA 40mA 60mA
High-level output Min Vcc*70% Min Vcc-2.5V Min Vcc-1.5V Min 3.4V
Low-level output Max 0.4V Max 0.4V Max 0.8V Max 0.4V
Rise Time Tr Max 1us Max 1us Max 1us Max 200ns
Fall  Time Tr Max 1us Max 1us Max 1us Max 200ns
Max Responding Frequency 150kHz 150kHz 150kHz 150kHz
 Mechanical Specification
Max speed(r/min) Starting Torque Max. Shaft Loading Shocking Vibration
5000 <0.03Nm Radial:15N, Axial:10N 50G/11ms 10G 10-2000Hz
Rotor  Inertia Working Temperature Storage Temperature Protection Grade Weight
4*10-8Kgm2 -25~80℃ -30~85℃ IP51 60g



Connection Table

Signal A B Z A(-) B(-) Z(-) Vcc GND
Color Green White Yellow Brown Grey Orange Red Black



Dimensions(mm)




Product Pictures

ISC2504-001E-200B-5C 1.jpg
