LB DB Bellows encoder flexible coupling screw stepper servo motor torque couplings
Oldham coupling consists of two half-open on the end face of the coupling groove and a disc with protruding teeth on both sides of the intermediate composition. Protruding teeth can be due to the slide in the groove, it can compensate for installation and operation when the relative displacement between the two shafts.
online service
| d1 | d2 | D | L | L1 | g | M |
| 4 | 4 | 19 | 30 | |||
| 8 | 8 | 19 | 30 | 3.5 | - | M3 |
| 4 | 8 | 19 | 30 | |||
| 6 | 6 | 25 | 38 | |||
| 10 | 10 | 25 | 38 | 4.5 | - | M3 |
| 6 | 10 | 25 | 38 | |||
| 6 | 6 | 32 | 48 | |||
| 14 | 14 | 32 | 48 | |||
| 6 | 14 | 32 | 48 | |||
| 6 | 6 | 38 | 60 | |||
| 18 | 18 | 38 | 60 | |||
| 6 | 18 | 38 | 60 | |||
| 6 | 6 | 44 | 72 | |||
| 20 | 20 | 44 | 72 | |||
| 6 | 20 | 44 | 72 | |||
| 8 | 8 | 55 | 82 | |||
| 24 | 24 | 55 | 82 | |||
| 8 | 24 | 55 | 82 |
Welcome to our website! Please send your words at any time in the following form and ask us, we will contact you and provide you with the corresponding service as soon as possible. Please write in English.
LD Single shrapnel Single diaphragm coupling high torque stepper servo motor coupling Plum
Diaphragm consists of several groups with bolts staggered with two coupling halves, each of the diaphragm by a set number of sheets stacked together, diaphragm coupling by elastic deformation of the diaphragm to compensate for the relative displacement of the two axes of the Union, is a high-performance metal stronger coupling element, do not run oil, more compact structure, high strength, long life, no rotation gap, independent of temperature and oil slicks, with acid, alkali corrosion, suitable for high-temperature, high-speed, medium corrosive environmental conditions of the drive shaft
Learn More
Clamping LT encoder coupling
◆introduction
Flexible couplings are offered in the industrys largest variety of stock bore/keyway combinations. These couplings require no lubrication and provide highly reliable service for light, medium, and heavy duty electrical motor and internal combustion power transmission applications. Applications include power transmission to industrial equipment such as pumps, gear boxes, compressors, blowers, mixers, and conveyors.
LP 6x6 D16 L24 series coupling encoder motor torque spring Flexible coupling
◆introduction
Flexible couplings are offered in the industrys largest variety of stock bore/keyway combinations. These couplings require no lubrication and provide highly reliable service for light, medium, and heavy duty electrical motor and internal combustion power transmission applications. Applications include power transmission to industrial equipment such as pumps, gear boxes, compressors, blowers, mixers, and conveyors.
YUMO 6mm Plastic Quick Encoder Coupling
Plastic type;
It can be applied to connect the eccentric shaft, can greatly adjust concentricity;
It can adjust the height of the products in the scope of use.
Model:LS D20-30 -L40 6*8.2
Brand:YUMO
Code:YM0000541
MOQ:25
